2 Pedrick A-7 Rotary Compression Bender #3230


2" Pedrick A-7 Rotary Compression Bender #3230

Condition: Good

Stock Number: 3230



Click to view larger photo

Request A Quote On Our Stock Number: 3230 2 Pedrick A-7 Rotary Compression Bender #3230Request a quote on stock# 3230
SpecificationDescription
Pipe Capacity2" Sch 80
Tube Capacity2.37" x .218
Bending Moment28,500 in - lbs
Rounds, Solid1.75" OD
Spindle Diameter3"

Weight2000 lbs
Dimensions40" x 40" x 35"


YouTube Video: https://youtu.be/U0jaLyQm2i0

Equipped With:
Die Set for Flat Bar 1/2: x 2" Flat Bar, easy way; Caster Mounted;

Model A-7 Bending Machine
The Model A-7 is the most popular bending machine manufactured by PEDRICK. It is a heavy duty version of the Model A-5. The Model A-7’s primary application is for bending 1/2 inch – 2 inch schedule 80 pipe for small bore process piping for plant maintenance and many original equipment manufacturing (OEM) applications. Bends produced on a 3D bend radius meet ASME B3 & American Petroleum Institute (API) specifications for ovality (flattening) and wall thinning. Bends produced on a 5D bend radius meet Nuclear Regulatory Commission (NRC) & United States Navy (USN) specifications.
