Request a quote on stock# 3210| Specification | Description |
|---|---|
| Cuts Keywasy | 1/16" to 1-1/4" |
| Maximum Length of Cut | 9" |
| Length of Stroke | 3"; 4-1/2"; 6"; 7-1/2"; 9" |
| Stokes Per Minute | 34 |
| Feeds (3) | .002, .004, .006 IPS |
| Largest Diameter Cutter Bar | 1-1/4" |
| Distance from Cutter to Column (Min-Max) | 1" - 16-1/4" |
| Maximum Distance Under Column Clamps | 14" |
| Distance Between Clamps | 25-1/2" |
| Table Size | 24" x 27" |
| Weight, estimate | 1150 lbs |
| Motor 230/460/3/60 | 2 HP |
| EQUIPPED WITH | |
| Automatic Table Feed and Stop | |
| Centering Vee | |
| Swinging Clamp Bar | |
| Cutter Bar | |
| Bijur Lube | |
